RHB1-2G LED UFO High Bay
The RHB1-2G is a compact and lightweight LED UFO high bay designed for exceptional durability and practicality, with field-selectable wattage and color temperature, IP65-rated sealed housing, and selectable beam angles for commercial, industrial, and retail applications.
Inventory and Lead Time
Contact us for availability and pricing information.
Need assistance?
Call us at
(866) 471-7711
RHB1-2G LED UFO High Bay
RHB1-2G LED UFO High Bay
Contact for Pricing
Downloads & Resources
Product Overview
Features
- Housing is completely sealed against moisture and environmental contaminants, IP65 rated.
- Sealed enclosure complies with NSF technical specs for illumination of food-grade non-splash zones.
- Corrosion-resistant powder coating provides protection and architectural appearance while adapting well to the environment.
- Thermally and electrically separated design ensures superior heat management to optimize performance and long life.
- Sensor receptacle pre-installed.
Optic
- Polycarbonate optical lens featuring IK08 impact resistance.
- Anti-UV prismatic translucent lens designed to shape light uniformity and control glare.
- Field-selectable beam angle (70°, 90°, 110°).
Mounting
- Hook Mount is standard.
- Conduit pendant mount, optional (3/4" pipe by others).
- Trunnion mount, optional.
LED
- Lumileds 2835.
- Field-selectable wattage levels: 100%, 80%, 60%.
- Field-selectable Color temperature: 3500 / 4000 / 5000 (K).
- Color rendering index: >80.
- Scalable lumen packages from 13,600 to 50,000 lumens.
- Estimated L70: 50,000 hrs.
Electrical
- Input voltage: 120-277Vac, 50/60Hz (std.).
- 277-480Vac (optional).
- PF > 0.9, THD <20%.
- 0-10V, 10%–100% dimming standard.
- Built-in surge 6Kv.
- Operating temperature: -40°C to 55°C (-40°F to 131°F).
- Operating temp. with EM: 5°C to 55°C (41°F to 131°F).
Listing
- UL, cUL listed for wet location.
- IP65 rated.
- 5 years limited warranty.
- ARRA compliant (optional).
Specifications
Ordering Information
- BAA, BABA or ARRA Compliant: ARRA only
Need a Custom Configuration?
Our team can help you specify the perfect configuration for your project. Contact us for custom options or integration assistance.
